Welcome to the Bathroom Brands Technical Whitebook

search autorenew

Freestanding 650 vanity unit with drawers & Minerva® White with vanity bowl
asaq2.Model.Web_product_new?.web_name
Product Options
Colour options: furniture
Freestanding 65 Vanity Unit with 2 drawers - Dark Olive and Minerva black granite worktop with integrated white basin Dark Olive Freestanding 65 Vanity Unit with 2 drawers - Sand and Minerva black granite worktop with integrated white basin Sand Freestanding 65 Vanity Unit with 2 drawers - Matt White and Minerva black granite worktop with integrated white basin Matt White Freestanding 65 Vanity Unit with 2 drawers - Classic Grey and Minerva black granite worktop with integrated white basin Classic Grey Freestanding Basin Unit Drawers Matt Green Matt Green
Worktop options
Freestanding 65 Vanity Unit with 2 drawers - Dark Olive and Minerva Carrara white worktop with integrated white basin Minerva Carrara white worktop Freestanding 65 Vanity Unit with 2 drawers - Dark Olive and Minerva white worktop with integrated white basin Minerva white worktop Freestanding 65 Vanity Unit with 2 drawers - Dark Olive and Minerva black granite worktop with integrated white basin Minerva black granite worktop
Alternate Text
As Shown
BB66 Minerva black granite with vanity bowl
FF9O Freestanding Basin Unit with drawers
Colour
BB66 - worktop with intergrated basin - black granite
FF9O - base unit - Dark Olive
Material
BB66 - worktop with intergrated basin - minerva solid surface material
FF9O - base unit - Engineered Wood - MDF
Size
FF9O - 548 x 666 x 820mm
Nett Weight
BB66 - worktop with intergrated basin - 22kg
FF9O - base unit - 34kg
Gross Weight Including Packaging
BB66 - worktop with intergrated basin - 24kg
FF9O - base unit - 39.5kg
Packed Dimension
BB66 - 745 x 625 x 255 = 0.1187 m3
FF9O - 730 x 615 x 885 = 0.3973 m3
Tap Hole Options
Tap holes are drilled by the installer.
Guarantee
10 year guarantee*
*Full terms & conditions here
Standards Information
EN14749:2016
Additional Information
Minerva worktops are supplied with an integrated bowl with overflow, and no tap holes. Tap holes are drilled by the installer in the required position and configuration. A template is provided with the Minerva tops indicating tap hole positions and sizes.
A lacquered top coat with 3 layers of primer featuring UV stabilization to minimise colour fading from exposure to sunlight.
Drawers are soft closing
Chrome plated metal handles
Fully assembled
A backsplash is supplied with the worktop but is optional as to whether you want to use it. This can be fit into place using silicon.
SP999-O bottom drawer (panel & internal) for Burlington freestanding unit — Dark Olive
SP670 one set of drawer runner 400mm for Burlington units
SP758 plinth for FF8O, FF9O
SP998-O top drawer (panel & internal) for Burlington freestanding unit — Dark Olive
Downloads
  • Instructions - PDF - FF9O (English)
  • 3D DWG - File - DWG  -  FF9O_BB66 (90527.dwg)
  • 3D DXF - File - DXF  -  FF9O_BB66 (90527.dxf)
  • 3D IGS - File - IGS  -  FF9O_BB66 (90527.igs)
  • 3D RFA BIMM Objects - File - RFA  -  FF9O_BB66 (90527.rfa)
  • Product image 1 - jpg
* Please note that some of the drawings might not be drawn to scale. Please refer to actual dimensions marked on the drawings.
