Burlington bath taps
asaq2.Model.Web_product_new?.web_name
Product Options
Tap Head Options (Chrome Finish Shown)
Claremont Regent bath tap - deck mounted Claremont Anglesey Regent bath tap - deck mounted Anglesey Birkenhead Regent bath tap - deck mounted Birkenhead Handle_v2.jpg Kensington
Quarter turn options
qt_done.jpg quarter turn
Tap Base options
Kensington bath tap - deck mounted Standard base Kensington Regent bath tap - deck mounted Regent base
Indicies & lever finish
Kensington Regent bath tap - deck mounted White Kensington Medici Regent bath tap - deck mounted Medici Kensington Regent bath tap - deck mounted Black
Alternate Text
As Shown
T4 Kensington tap handles
T4A Regent large pair of tap bases
T7_QT Quarter turn bath pillar taps
KER3-QT  -  Combined product code
Colour
T4 - tap handle - Polished Chrome
T4A - regent tap base - Polished Chrome
T7_QT - tap - Polished Chrome
Material
T4 - tap handle - Brass
T4A - regent tap base - Brass
T7_QT - tap - Brass
Size
T4 - 94 x 27 x 23.2mm
T4A - 70 x 250 x 27mm
T7_QT - 150 x 165 x 139mm
Nett Weight
T4 - tap handle - 0.29kg
T4A - regent tap base - 0.4kg
T7_QT - tap - 1.32kg
Gross Weight Including Packaging
T4 - tap handle - 0.34kg
T4A - regent tap base - 0.5kg
T7_QT - tap - 1.62kg
Packed Dimension
T4 - 105 x 70 x 35 = 0.0003 m3
T4A - 76 x 76 x 70 = 0.0004 m3
T7_QT - 325 x 195 x 55 = 0.0035 m3
Guarantee
15 year guarantee*
*Full terms & conditions here
Standards Information
BS EN 200:2008
BS EN 817:2008
Additional Information
Supplied with flow straighter for use with low water pressure
Also supplied with aerator for use with high water pressure
Flow Rates
System Pressure 0.2 bar 0.5 bar 1 bar 2 bar 3 bar 4 bar 5 bar
Spout (straightener) 8.6  10.4  12.2  15.4  17.6  n/a  n/a
Spout (aerator) 4.3  7.4  8.5  10.2  11.6  n/a  n/a
SP523 chrome finish Bell shape part for T5, T6, T7, T8, T9, T10, T11, T12, T13, T14, T15, T16, T26, T24, T25, T27 and relative Quarter turn taps
SP931 decorative cap of Burlington tap handles - cold
SP930 decorative cap of Burlington tap handles - hot
SP93 fixing screw and washer for all finishes products of valve handle (T1, T2, T3, V1, V2, V3)
SP449 flow straightener for all finishes products of T5, T5-QT, T6, T6-QT, T7, T7-QT, T12, T12-QT, T13, T13-QT, T14, T14-QT, T15, T15-QT, T16, T16-QT, T26, T26-QT, CH19, CH20, CH21, CH22, CH23
SP92 G3, 4 fixing nut and washer for all finishes products of T7, T18, T14-QT
SP72 T5, T6, T16 1, 2 and T7 3, 4 quarter turn COLD cartridge
SP71 T5, T6, T16 1, 2 and T7 3, 4 quarter turn HOT cartridge
SP99 the fixing screw and washer for T1, T2, T3, T4, V1, V2, V3
SP1093 thread tube O ring seal for all finishes products of T16, T16-QT, T14, T14-QT, T24, T24-QT, T25, T25-QT, T26, T5, T5-QT, T6, T6-QT, T7, T7-QT
Downloads
  • Instructions - PDF - T4 (English)
  • Instructions - PDF - T7_QT (English)
  • Instructions - PDF - T7_QT (French)
  • Instructions - PDF - T4 (French)
  • 3D DWG - File - DWG  -  KER3-QT (T7.dwg)
  • 3D DXF - File - DXF  -  KER3-QT (T7.dxf)
  • 3D IGS - File - IGS  -  KER3-QT (T7.igs)
  • 3D IGS - File - IGS - T4 (t4.igs)
  • 3D DWG - File - DWG - T7_QT (T7.dwg)
  • 3D DXF - File - DXF - T7_QT (T7.dxf)
  • 3D IGS - File - IGS - T7_QT (T7.igs)
  • 3D DWG - File - DWG - T4A (T4A.dwg)
  • 3D DXF - File - DXF - T4A (T4A.dxf)
  • 3D IGS - File - IGS - T4A (T4A.igs)
  • Product image 1 - jpg
  • Product image 2 - jpg
* Please note that some of the drawings might not be drawn to scale. Please refer to actual dimensions marked on the drawings.
