Burlington 3 tap hole basin mixer with pop-up waste

Product Options

Finish Options

Birkenhead Regent 3 tap hole mixer with pop up waste

Chrome

Tap Head Options (Chrome Finish Shown)

Claremont

Anglesey

Birkenhead

Quarter turn options

quarter turn

tradional screw-down

Tap Base options

Birkenhead 3 tap hole mixer with pop up waste

Standard base

Regent base

Indicies & lever finish

White

Medici

Black

As Shown

T14 Three tap hole tap with pop up

T4B Regent small single tap base

T3 Birkenhead tap handles

BIR12 - Combined product code

Colour

T14 - tap - Polished Chrome

T4B - regent tap base - Polished Chrome

T3 - tap handle - Polished Chrome

Material

T14 - tap - Brass

T4B - regent tap base - Brass

T3 - tap handle - Brass

Size

T14 - 150 x 248 x 125mm

T4B - 55 x 55 x 29mm

T3 - 65 x 65 x 23.3mm

Nett Weight

T14 - tap - 2.22kg

T4B - regent tap base - 0.45kg

T3 - tap handle - 0.175kg

Gross Weight Including Packaging

T14 - tap - 2.85kg

T4B - regent tap base - 0.63kg

T3 - tap handle - 0.2kg

Packed Dimension

T14 - 440 x 310 x 65 = 0.0089 m3

T4B - 65 x 65 x 35 = 0.0001 m3

T3 - 70 x 65 x 65 = 0.0003 m3

Guarantee

15 year guarantee*
*Full terms & conditions here

Standards Information

BS EN 200:2008

BS EN 817:2008

Additional Information

Gold and Nickel finish is only available with the Claremont handle

Gold and Nickel finish is only available with white indicies

Gold and Nickel finish is only available with the quarter turn option

Supplied with flow straighter for use with low water pressure

Also supplied with aerator for use with high water pressure

Supplied with pop up waste.

Flow Rates

System Pressure	0.2 bar	0.5 bar	1 bar	2 bar	3 bar	4 bar	5 bar
Spout (straightener)	9.5	15.8	17.2	19.3	21.2	n/a	n/a
Spout (aerator)	4.1	7.7	8.9	10.6	11.6	n/a	n/a

Spare parts

SP450	aerator for all finishes products of T5, T5-QT, T6, T6-QT, T7, T7-QT, T12, T12-QT, T13, T13-QT, T14, T14-QT, T15, T15-QT, T26, T26-QT, CH19, CH20, CH21, CH22, CH23
SP1726	back bottom washer for SP28
SP523	chrome finish Bell shape part for T5, T6, T7, T8, T9, T10, T11, T12, T13, T14, T15, T16, T26, T24, T25, T27 and relative Quarter turn taps
SP931	decorative cap of Burlington tap handles - cold
SP930	decorative cap of Burlington tap handles - hot
SP468	decorative cover for T14
SP93	fixing screw and washer for all finishes products of valve handle (T1, T2, T3, V1, V2, V3)
SP449	flow straightener for all finishes products of T5, T5-QT, T6, T6-QT, T7, T7-QT, T12, T12-QT, T13, T13-QT, T14, T14-QT, T15, T15-QT, T16, T16-QT, T26, T26-QT, CH19, CH20, CH21, CH22, CH23
SP92	G3, 4 fixing nut and washer for all finishes products of T7, T18, T14-QT
SP451	key for all finishes products of T5, T5-QT, T13-QT, T13, T12-QT, T12, T16-QT, T16, T14, T14-QT
SP634	pair of flexible hoses for all finishes products of T14-QT, T14, T26 (360mm)
SP644	pair of valve body including cartridges for T14
SP974	plug of pop up waste for product T14, T14-QT, T14 BLA, T14-QT BLA, T14 MED, T14-QT MED, T26, T12, T12-QT, CH20, CH22, T15, T15-QT, CH23
SP889	pop up basin waste of product T14, T14-QT, T26 (excluding the vertical pop up waste control rod)
SP1716	rod pipe in chrome finish for product T14, T14-QT, T14 BLA, T14-QT BLA, T14 MED, T14-QT MED
SP1723	spout for T14, T14-QT, T14 BLA, T14-QT BLA
SP149	t-piece connecting hoses to spout -T14
SP45	T1, T2, T3 'Hot' and 'Cold' ceramic indice
SP48	T12, T13, T14, T15, T16, V25, V34, V36 'B' logo ceramic indice (D=22.2mm)
SP30	T14 1, 2 full turn cartridge
SP102	T14, T14-QT pop up waste control rod
SP99	the fixing screw and washer for T1, T2, T3, T4, V1, V2, V3
SP1093	thread tube O ring seal for all finishes products of T16, T16-QT, T14, T14-QT, T24, T24-QT, T25, T25-QT, T26, T5, T5-QT, T6, T6-QT, T7, T7-QT
SP1285	washers of pop up rod for all finishes products of T14, T14-QT, T26
