CTA11 Sapphire basin mixer with pop up waste |
CTA11 - tap - chrome plated |
CTA11 - tap - brass |
CTA11 - tap - 1.7kg |
CTA11 - tap - 2kg |
CTA11 - 320 x 225 x 110 = 0.0079 m3 |
15 year guarantee*
*Full terms & conditions here |
Level 10 salt spray tested |
Chrome plated to EN248:2002 |
EN817:2008 |
Sanitary tapware. Mechanical mixing valves (PN 10). General technical specifications |
EN200:2008 |
Sanitary tapware. Single taps and combination taps for water supply systems of type 1 and type 2. General technical specification |
Supplied with flow straighter for use with low water pressure |
Also supplied with aerator for use with high water pressure |
All mixers work on 0.2 bar to 5 bar pressure |
System Pressure | 0.2 bar | 0.5 bar | 1 bar | 2 bar | 3 bar | 4 bar | 5 bar |
---|---|---|---|---|---|---|---|
Spout (straightener) | 3.61 | 6.29 | 9.36 | 13.56 | 16.76 | n/a | n/a |
Spout (aerator) | 2.26 | 3.79 | 5.4 | 7.67 | 9.42 | n/a | n/a |
