Medici Standard CC WC with 520 Lever Cistern

As Shown

P5 M −

C1 M −

S51 −

A51CHR −

Guarantee

Lifetime guarantee*
*Full terms & conditions here

Standards Information

BS EN 14055:2018

BS EN 997:2018

BS EN 33:2019

Additional Information

Water Inlet valve hole is located on the base of cistern tank on the right hand side

Bottom inlet valve (SP5A). Back inlet valve available as optional item (SP511).

SP511 : Back entry kit for C1/C2/C3/C4/C30, including back entry inlet valve with flexible hose and plug.

Dual flush cistern fittings with ceramic lever on the right.

Press lever down for 6 litre flush and up for 3 litre flush.

Regal Height pan ( floor to pan rim height 48cm ) available : P12.

Metal connection bracket.

Close coupled wc must be used with standard Burlington toilet seats.

Supplied with floor fixings.

Recommended to be used with cistern tank isolation valve W25.

P trap standard height pan - height from floor to pan rim is 42cm.

Ceramic soil connection pipes : straight connector to the wall : C29 M. The S trap connector bending down to the floor : C26 M.

SP511	back entry kit for C1, C3, C2, C4, C30, ARC5, including back entry inlet valve with flexible hose and plug
SP1021	bottom sealing washer of flush valve for product C1, C3, C3, C4
SP84	cistern flush valve with control cable for cistern fitting SP5 (excluding lever and inlet valve)
SP508	kit for close couple cistern
SP507	kit for low level installation for close coupled cisterns C1, C2, C3, C4, T71 CHR
SP17	screw fixing pack for pan and bidet
SP802	the bigger stopper for SP5A, ARCSP7, C24C, SP7
