Svelte Illuminated Mirror
As Shown
| SE6060 Svelte Illuminated Mirror |
Material
| SE6060 - illuminated mirror - Glass |
Nett Weight
| SE6060 - illuminated mirror - 6.245kg |
Gross Weight Including Packaging
| SE6060 - illuminated mirror - 7.14kg |
Packed Dimension
| SE6060 - 80 x 670 x 670 = 0.0359 m3 |
Guarantee
|
5 year guarantee*
*Full terms & conditions here |
Standards Information
|
BS EN 60598-2-1:1989 |
|
BS EN 60598-1:2015 |
|
UTE C 15-801:2012 |
|
BS EN 62493:2015 |
|
BS EN 55015:2013+A1:2015 |
|
BS EN 61000-3-2:2014 |
|
BS EN 61000-3-3:2013 |
|
BS EN 61547:2009 |
Additional Information
|
Demister Pad: 310 x 450mm 21w |
|
Temperature change |
|
5mm mirror glass with safety film backing |
|
PIR sensor on/off switch |
|
Dim-able |
|
Low spot low energy LEDs |
|
Adjustable light temperature from 3000K (warm white) to 6000K (daylight) |
|
IP44 RATED CLASS I rated |
|
Hanging Options: Landscape |
| 15WLEDD | 15W LED DRIVER |
Downloads
- Specifications - PDF - SE6060
-
2D CAD-File - DWG -
SE6060
(SE6060-cad.dwg)
-
2D Drawing - PDF -
SE6060
(SE6060-cad.pdf)
2D Drawing - PDF - SE6060
