Svelte Illuminated Mirror
As Shown
| SE12070 Svelte Illuminated Mirror |
Material
| SE12070 - illuminated mirror - Glass |
Nett Weight
| SE12070 - illuminated mirror - 12.985kg |
Gross Weight Including Packaging
| SE12070 - illuminated mirror - 14.86kg |
Packed Dimension
| SE12070 - 80 x 1270 x 770 = 0.0782 m3 |
Guarantee
|
5 year guarantee*
*Full terms & conditions here |
Standards Information
|
BS EN 60598-2-1:1989 |
|
BS EN 60598-1:2015 |
|
UTE C 15-801:2012 |
|
BS EN 62493:2015 |
|
BS EN 55015:2013+A1:2015 |
|
BS EN 61000-3-2:2014 |
|
BS EN 61000-3-3:2013 |
|
BS EN 61547:2009 |
Additional Information
|
Demister Pad: 310 x 450mm 21w |
|
Touch controls allow you to adjust the brightness and colour |
|
5mm mirror glass with safety film backing |
|
Temperature change |
|
Dim-able |
|
Low spot low energy LEDs |
|
Adjustable light temperature from 3000K (warm white) to 6000K (daylight) |
|
IP44 RATED CLASS I rated |
|
Hanging Options: Landscape |
Downloads
- Specifications - PDF - SE12070
-
2D CAD-File - DWG -
SE12070
(SE12070-cad.dwg)
-
2D Drawing - PDF -
SE12070
(SE12070-cad.pdf)
2D Drawing - PDF - SE12070
