Welcome to the Bathroom Brands Technical Whitebook


Three-panel bathscreen
asaq2.Model.Web_product_new?.web_name
As Shown
BS4 Three panel bathscreen
Gross Weight Including Packaging
BS4 - bathscreen - 23.4kg
Guarantee
Lifetime guarantee*
*Full terms & conditions here
Standards Information
BS EN14428:2015
BS EN 12150-1:2015
Additional Information
Can be fitted to either left or right hand baths
Safety glass with 3M Easy Clean Coating
Screen opens both inwards and outwards
SP878 bottom hinge D of product BS4, BS5
SP495 bottom waterproof strip for BS4 and BS5
SP1500 BS4L, R bottom seals (old version)
SP858 connecting part of hinges on product BS4, BS5
SP859 cover of hinges on product BS4, BS5
SP728 left cover for bottom waterproof barrier for BS4, BS5 (B112 )
SP805 right cover of bottom waterproof barrier for BS4, BS5 (B114 )
SP467 seal between the glass panels for BS4, BS5
SP875 top hinge A of product BS4, BS5
SP876 top hinge B of product BS4, BS5
SP1134 wall profile for BS4, BS5
SP496 water barrier for BS4 and BS5
